MENNEKES Panel mounted socket with TwinCONTACT 3049

Panel mounted socket with TwinCONTACT 3049

Poles
Voltage
Clock position
  • screwless spring terminals
  • standard flange dimensions
  • 20° inclination
  • sockets are designed for adding an auxiliary contact switch
  • Part no.3049
  • EAN4015394221654
  • Std. Pack. 10
You can manage our products in various lists in the shopping list / shopping basket area.
Please give the new list a name
  • Please enter a list name
  • The list name already exists
  • Please enter a valid list name
TwinCONTACT

Screwless - TwinCONTACT

Screwless spring terminals

Technical specifications

Panel mounted socket with TwinCONTACT 3049

Ampere 16 A
Poles 4 p
Voltage 500 V
Clock position 7 h
Hertz 50-60 Hz
Connection technology Screwless - TwinCONTACT
Contact standard
Protection type IP44
Flange 85x85 mm
Fixing hole 70x70 mm
Inclination 20 °
Weight 140 g
Certifications EAC

Directives

Panel mounted socket with TwinCONTACT 3049
